- 2024
- Aug
- 7
My haul from the 2024 Columbus Hamfest
I brought home some things that I didn’t need, but isn’t that the point of this kind of show?
A Vishay decade box and a frequency counter / generator. They both seem to work well enough for the age. There’s also some high-voltage mica capacitors sitting on top of the decade box. Those were a buck, and I said why not?
I can’t go to a show without bringing home at least one meter. Unfortunately, this one seems to have some issues, it will zero but not read. I need to open it up and make sure that any batteries left in it aren’t corrodeedoodled all over the place.
This PACO generator is the same as one I have in better condition. This one is a $5 parts unit.
This is a PACO power supply that came from the same vendor as the generator, also $5. It’s an interesting piece, being an early bench supply for audio work, but in reality it’s a glorified battery charger. Stay tuned for a teardown on this guy.
No idea what this is, my fellow show-goer suggested it was some sort of early electronic switch for process industry. He’s probably right, but I got it simply for the cheapness of a 250VAC transformer that could be reused.
That’s it for this year. I’ll be posting show pictures, and some other, recent engine shows as soon as I can get the images cleaned up.
- 2024
- Aug
- 4
It’s time to clean out some stuff - maybe to Dayton 2025?
One of my fellow show-goers was talking about taking some of the audio gear he collected to Dayton in 2025, and we’ll set up a table on the flea market. This sounds like a cool idea to me, I’ve attended shows but never had a sales table.
In the spirit of things, I took a look at what I’ve collected over the years that’s never going to go anywhere, and there’s a bunch. It’s time to start cleaning out, and I have a bunch of things that could go. Where does it all come from?
See you there, and maybe you can take something home! It’s cheap cheap cheap!
(If you see something you like, drop me a line on LinkedIn and we’ll see about a deal!)
- 2024
- Aug
- 4
Pictures from recent shows are on the way!
Pictures from the Columbus Hamfest, Cool Spring Power Museum, and Miami Valley Steam Thresher Association shows are all in the works. There’s simply a lot of them and I have been a lazy little pig. Check back in the next few weeks and I promise that you’ll have some cool stuff to browse!
They’ve all been posted! Sorry it took so long on some of those…
- 2024
- Aug
- 4
The dial lamp can be more important than you think.
You’ll notice there’s a #47 lamp (Part# LM1) in the circuit for a lot of transformerless sets like the S-38C. It’s fed by a special tap on the rectifier tube:
It’s just a light bulb, right?
Yes and no. If you look at where it’s at in the circuit, it’s actually helping feed input current to the plate of the rectifier. This has the effect of both providing said current for the tube, and limiting the current available to the tube - you can draw about 60mA in this configuration.
So, do you need this bulb?
Again, yes and no. There are configurations where the tube is fed directly from the AC line, and this is a perfectly acceptable method. However, in our case of having the bulb, you have a bit of voltage drop to the plate which results in a lower output voltage, so you’d need to take this into account if removing the bulb - i.e. you need a resistor for some voltage drop. There’s also the fact that it is providing the AC current input - if you remove it, all of your current is now being sourced by the connection from the heater, and you’re stressing the tube. The radio won’t quit - but it just told you “Hey, I need service.”
In this case, the bulb is a component of the circuit that does more than provides light - it’s ballast for the rectifier and is providing a path for input current. It’s as necessary as the rectifier itself. You can’t replace this with anything other than a incandescent bulb without modification, so don’t grab an LED replacement for this one.
Fortunately, places like Antique Electronic Supply sell packs of 10 for under a fiver, so you can pick up a bunch and drop them in your parts bin. You probably want to do that anyway to get one that isn’t more tungsten boil-off than light bulb.
- 2024
- Jul
- 31
Replacing the filter capacitors in a Hallicrafters S-38C
One of the things I picked up at Dayton this year was a really nice example of an S-38C multi-band radio. Completely untouched inside, it of course has bad filters. That’s par for the course for one of these. (It probably also has some silver mica disease, but that’s another day’s problem!)
Replacing them is easy enough, but it all depends on how you want to do it. Some prefer to keep it original, opening up the can on the multi-section device and putting new components inside. Others just wrap capacitors wherever there’s a place to put them. I’m thinking of going a different direction with this one.
Most of Hallicrafters low-end transformerless sets used similar multi-section capacitors and dropping resistors.
(Schematic from the Riders Manual.)
Some, like this one, used a 220Ω and 1kΩ resistor, others (like the S-95) used a 470Ω instead of the 1K.
So…why not create some sort of universal PCB that can drop in and replace all of the filter capacitors, sans the cathode bypass capacitor used in the audio stage of some of the units?
I had thought of using axial devices, but those can get expensive. What’s not expensive, and are compact and readily available? Surface mount parts. A small board could be created with three capacitors and space for the two dropping resistors, pre-assembled (or partially, depending on what you’re trying to fix,) and either double-side taped in or bolted down. The board wouldn’t need to have any through holes, wires could simply lay on pads and be soldered down. 5W resistors and 160V capacitors exceed original specifications, and would be easy to install on the board.
There’s certainly plenty of room in the device once the original can has been removed.
Wow, those feet are in bad shape…need to find some replacements!
I know that idea will offend some purists, but that’s not my concern here. I want to get the device back up and running with good quality parts that fit in the space required, without drilling a lot of holes or simply shooting parts all over the place.
I just need to brush up on my PCB skills, and lay out the board for sizing. Stay tuned!
- 2024
- Jul
- 29
A recruiter once told me that a company was a poor choice. They were right.
A recruiter once told me that a company (that I had asked about) was generally known in the local industry for wanting to pay substantially under market - trying to be as cagey about it as they could. His comments about the place were substantially more colorful, but that was the gist of the statements, along with a “probably not going to be worth your time.”
The person telling me this had no connection to the company, so I put the info in my files, and thought that maybe they just had a bad experience with the place.
No, they were correct - I had a few offers to interview with this place over the years, and the pay for skills desired was very poor - probably about 1/2 to 2/3 of what others were paying. I turned down the few contacts I had with a “Thank you, but there’s nothing about your offer that makes me want to pick up and move across the state.
The last contact I had with this company, the person contacting me became somewhat (not really) angry that I refused to even consider the position. To be fair, I did have an online profile that stated a range of pay I was interested in, but this also was posted with the caveat of being for local positions only. Any movement would require reassessment of those rates. When I pointed this out, the person passive-aggressive told me “Oh, ok.” That was the last time I heard from them. I’ve since taken a look at reviews on job sites, and those suggest that things have not changed - or even increased a whole lot, if at all. There’s a lot of talk on these reviews about the complete lack of awareness and organization within the company.
I appreciate that information to this day. When I’m told there’s something not right about what I’m looking at, I make a point to at least investigate the complaint on my own. Even if the complaint seems to be unfounded, I still keep that in my back pocket.
- 2024
- Jul
- 26
Creating a useful 404 page for this blog (and flatpress in general?)
When I was setting up redirects and closing pygg.xyz for the last time, I toyed with a bunch of ideas about how to properly tell the viewer that they had either reached their destination, or that the link they had was no longer valid. If someone had a link that wasn’t valid, I could simply let it go to the host’s 404 page - that’s not useful to the viewer, however.
The first option I tried was creating a simple 404 page with some information and links. That’s fine, but it’s just not the best looking thing in the world. I quickly abandoned that for a page at the end of the blog, “posted” long before any of the real posts were made. This worked, but…
Anyone that has a website of any sort knows that you’re going to get slammed by bad actors looking for entry points. In this case, those bad actors assume that since it’s a “blog,” you’re running WordPress. According to the site logs, I was getting slammed by requests for things in associated directories. There were quite a few other things as well. SQL, Oracle, SAP…all of those were common things being probed. There were even a lot of things I didn’t know what they were until I looked them up.
I set up the page at the end of the blog and checked back the next day. Exactly what you’d think happened, did. Hundreds of “views” in 24 hours, and I can guarantee you that none of those were actual people looking at that page. The view counter slowly went up with each refresh, indicating that the attacks were continuous.
This isn’t necessarily a problem, but it is in a way. If I were to let that page sit there, the site statistics would eventually show that page as being the most popular one on the blog - it would literally dwarf all other posts because it was getting hundreds of “views” a day. I didn’t want that, I want to give you things you’re interested in seeing. An error page isn’t interesting when you’re browsing the popular posts page.
I settled on a compromise. I took a static snapshot of the 404 page from “View Source,” cleaned it up to remove anything that’s not going to update, and made it the “Not Found” page. It looks almost like a blog page and has all of the sidebar widgets for navigation. This gives the viewer plenty of explanation as to why they are there, and what is available to them if they want to continue. This seems like the best choice - I’m not polluting the site with fake views, and a viewer who arrives there by accident has plenty of ways to find other content while landing on a familiar looking page.
Of course, as I read that page, it will change. Some of the things I write just don’t make any sense, and as I run across other situations those need to be addressed. In all, I think it’s a good place to land if someone does happen to find a broken link.
Maybe I’ll sit down sometime and analyze the WordPress script kiddies’ requests and create a special page for them that sends them to some weird government org. Probably not, they can sit on the 404 page just like everyone else.
- 2024
- Jul
- 26
Fun with Chrome?
I’ve been messing with various ideas for where pygg.xyz should go after it’s hosting plan expired. I finally settled on just having it redirect to the top level of Projects, with any errors going to the 404 page at the very end of this blog. This was done with redirects set in the domain registrar’s control panel.
The 404 page will get it’s own post. Stay tuned
DNS takes a while to propagate through the system, so I waited a while. Flushed the DNS resolver cache. Firefox and other browsers said no problem, here’s your site!
Chrome? Doesn’t work.
Did you know chrome has it’s own resolver cache, and even clearing that seems to have issues? I didn’t either.
You can’t get to that resolver cache unless you know the magic words. Put chrome://net-internals/#dns into the URL bar of Chrome and you’ll get to a simple text page where you can look up a named site and see it’s address, and/or clear the cache. Chromium browsers should follow this convention, but YMMV.
I cleared this cache on one machine, and my site started resolving. Another machine, and no luck. There seems to be differences between Chrome versions. That issue may cause some problems for people who have some very old links to this blog, but most of those should be gone by this point.
The moral of the story? There are more things to clear than you think there are, and even that may not work.
There was also some general crap going on with the redirects on the host. I cleaned those up and standardized them with my other domains, you shouldn’t have any issues getting here from there - but Chrome is still Chrome, and Chrome does what it wants.
- 2024
- Jul
- 23
The Columbus Ohio hamfest - Saturday August 3rd 2024
I’ve been attending this show for several years, it’s always got a good deal or two to be had. It’s one of those “get there when they open” shows.
There’s usually a food vendor on site, but you’re right in the middle of a lot of other options should you want something off-site.
2024 COLUMBUS HAMFEST
Saturday, August 3, 2024
8:00 am – 1:00 pm
Located at:
ALADDIN SHRINE CENTER
1801 Gateway Circle
Grove City, Ohio 43123
https://aladdinshrine.org/hamfest/
This is right off I-71, south of Columbus proper.
- 2024
- Jul
- 17
A cheap Chinese radio kit.
I picked this radio kit up from a popular import site. I’ve seen a couple of them built on random videos, and the price was right (under $10 shipped…) They work, but yeah, it’s cheap.
The kit consists of a case, board, parts, and “instructions.” No alignment notes or anything, so I hope this thing is 455Khz…
The instructions are literally just a schematic and parts placement diagram of sorts. It assumes you know how to align the radio, I guess!
If I get around to putting it together, it will be a bit of a challenge. Who knows when I’ll get to this.
